Balboa M-7 Heater Assembly 2"x15" 5.5kW 240V W/Mounting Studs & Sensors

Balboa M7 Complete Heater flow-thru assembly, stainless steel, 240v 5.5kw, 2 inch with external thermowell, 1 pressure tap, mounting studs, also includes 2 sensors and two 2 inch tail pieces. This Balboa M7 heater assembly was designed to fit the plastic control box; VS/EL2000/EL2001. Our Balboa M7 heater assembly is brand new and complete with both sensors mounted, and a brand new M7 heating element. Also included are both 2 inch split nuts, tailpieces and a pair of o-ring gaskets.

This heater is compatible with Balboa control systems with the following numbers:

53267	53267-01	53267-02	53527	53527-01	53527-02	53600	53600-01	53600-02
53602	53602-01	53603	53603-01	53608	53608-01	53608-02	53619	53649
53752	53752-01	53752-02	53787	53957	53957-01	53986	53986-01	53988
53988-01	54200	54200-01	54202	54291	54291-01	54291-02	54293	54293-01
54293-02	54337	54337-01	54337-02	54344	54350	54350-01	54352	54354
54356	54356-01	54356-02	54360	54366	54368	54368-01	54368-02
54371	54371-01	54371-02	54377	54377-01	54377-02	54380	54380-01	54380-02
54384-02	54390-02	54478	54478-01	54478-02	54491	54491-01	54491-02	54493
54585	54587	54603	54603-01	54635	54635-01	54637	54637-01	54639
54639-01	54645	54645-01	54661	54661-01	54707	54756	54762	54762-01
55023-01	55023-02	55056	55056-01	55056-02	55065	55065-01	55065-02	55066
55066-01	55066-02	55067	55067-01	55067-02	55068	55068-01	55068-02	55069
55069-01	55069-02	55100	55100-01	55173	55173-01	55178	55178-01	55178-02
55210	55227	55236	55240	55240-01	55257	55338	55363	55366
55371	55371-01	55373	55373-01	55375	55375-01	55476	55483	55488
55492	55501	55515	55515-01	55601	55636	55646	55664	55666
55695	55736	55736-01	55736-02	55796	55797	55811	55813	55833
55839	55839-01	55839-02	55848	55860	55944	55958	55958-01	56007
56007-01	56008	56008-01	56009	56016	56016-01	56018	56019	56020
56021	56056	56070	56075	56075-01	56075-02	56076	56134	56142
56150	56156	56174	56183	56185	56216	56216-01	56229	56230
59004	59004-01	59004-02

Housing Configuration	Straight
Heater Length	15"
Lead End Terminal Location	4-1/4"
Threaded Tap Orientation	None
Threaded Tap Location	13" From Leading End, 2" From Leading End
Kilowatts	1.375kW, 5.5kW
Voltage	115v, 230v
Sensor Stud Orientation	None
Mounting Stud Type	Fixed
Heater Size	2"
Heater Application	Balboa Water Group
Special Features	Grounding Stud, M7 Sensors
